Audit Trail Component , .net standard 2.1 + Full Source Code

Product Details

Audit Trail Component + Full Source Code

Version v1.0



Audit trail component stores database actions (Add, Update, Delete), business actions (you can specify them), sends notifications and logs its own errors, also it’s dynamic as it gives user the ability to specify [Business actions], [Emails that notifications will be sent to], [Notification’s subject] and [Notification’s Message], also you can search for all the data has been stored by the component by predefined methods.

Framework: .net standard 2.1

Packages :

  • Microsoft.EntityFrameworkCore.SqlServer 3.1.3
  • Newtonsoft.Json  12.0.3

Hangfire Packages :

  • Hangfire.AspNetCore
  • Hangfire.SqlServer

Features :

  • Store database actions and business actions.
  • Send notifications.
  • Log send notification process, and retry if it’s failed.
  • Log errors.
  • Dynamic: User can specify actions and emails and specify if the component should send notification when a specific action happened.

Recommendation :

use background job to execute component methods, to ensure that the original request time will not be increased.


Database Tables


to store actions lookup data


to make relation between [action], and emails, so if this action happened then the component will   send notification to the related emails with the specified message.


to store the audit data


to log the component errors


to store the notifications that the component will send to emails


to log the send notification process, component will store every (send email) retry and store if it’s done successfully or not with error message


How to Register


  • In your project, you need to install Hangfire nugetpackages [Hangfire.AspNetCore, Hangfire.SqlServer] ,or any package to perform background processing.
  • Also you need to implement[ IEmailService ] interface to send notification emails .


Startup class

  • In method [ConfigureServices]

        #region hangfire

            // Add Hangfire services.

            services.AddHangfire(configuration => configuration




                .UseSqlServerStorage(Configuration.GetConnectionString(“DefaultConnection”), new SqlServerStorageOptions


                    CommandBatchMaxTimeout = TimeSpan.FromMinutes(5),

                    SlidingInvisibilityTimeout = TimeSpan.FromMinutes(5),

                    QueuePollInterval = TimeSpan.Zero,

                    UseRecommendedIsolationLevel = true,

                    UsePageLocksOnDequeue = true,

                    DisableGlobalLocks = true



            // Add the processing server as IHostedService





            #region Audit

            services.AddScoped<IEmailService, EmailService>();


            //AddAuditTrail classes


                 new List<AuditActionDto> {

                    new AuditActionDto() { ActionCode =”CreateOrder”,SendNotification=true,NotificationFromEmail=”admin@gmail.com

                                        ,NotificationEmails=”ahmed@yahoo.com,ali@hotmail.com”,NotificationSubject=”subject “

                                        ,NotificationMessage=”sample message”},

                    new AuditActionDto() { ActionCode = “DeleteOrder”,SendNotification=true,NotificationFromEmail=”admin@gmail.com”,

  NotificationEmails=”ahmed2@yahoo.com,ali2@hotmail.com”,NotificationSubject=”subject “  ,

   NotificationMessage=”sample message2” },

                    new AuditActionDto() { ActionCode = “UpdateOrder” ,SendNotification=true},

                   new AuditActionDto() { ActionCode = “NewUpdateOrder” ,SendNotification=false}});



            //register background job to Check Notifications to send emails

            var sp = services.BuildServiceProvider().CreateScope().ServiceProvider;

            var notificationService = sp.GetService<INotificationPublicService>();

                 JobStorage.Current = new SqlServerStorage(Configuration.GetConnectionString(“DefaultConnection”),

                 new SqlServerStorageOptions


                CommandBatchMaxTimeout = TimeSpan.FromMinutes(5),

                SlidingInvisibilityTimeout = TimeSpan.FromMinutes(5),

                QueuePollInterval = TimeSpan.Zero,

                UseRecommendedIsolationLevel = true,

                UsePageLocksOnDequeue = true,

                DisableGlobalLocks = true


            RecurringJob.AddOrUpdate(() => notificationService.CheckNotificationsAndSend(), Cron.Daily);



How to create tables

  • Open [Package manager console] and in the [Default project] list .. select [AuditTrailComponent] project
  • Write the below commands
    • add-migration InitiatAudit -context AuditDbContext
    • update-database -context AuditDbContext


How to use


  • Inject this interface to your class [IAuditTrailService]
  • To store business action

BackgroundJob.Enqueue(() => AuditTrailService.SaveCustomActionsAuditTrailAsync(“DeleteOrder”, “sample data by hangfire”, “username1”));


  • To store database action ,use the below code before Entity framework save changes method

BackgroundJob.Enqueue(() =>AuditTrailService.SaveDbActionsAuditTrailAsync(ApplicationDbContext.ChangeTracker.Entries()

            .Select(a =>

            new DatabaseChangesDto


                Entity = a.Entity,

                OriginalValues = a.OriginalValues.ToObject(),

                CurrentValues = a.CurrentValues.ToObject()



  • To search for audit data

//Inject this interface [IAuditTrailService]

AuditTrailFilterDto model = new AuditTrailFilterDto {Audit_ActionCode=”DeleteOrder” };

var result=await AuditTrailService.Search(model);


  • To search for Notifications

//Inject this interface [INotificationPublicService]

NotificationFilterDto model = new NotificationFilterDto { Audit_ActionCode=”DeleteOrder” };

var result=await NotificationPublicService.SearchNotifications(model);


  • to search for notification log

//Inject this interface [IErrorLogPublicService]

NotificationLogFilterDto model = new NotificationLogFilterDto { };

 var result = await NotificationService.SearchNotificationLogs(model);


  • to search for error logs

//Inject this interface [IErrorLogPublicService]

ErrorLogFilterDto model4 = new ErrorLogFilterDto();

var result = await ErrorLogPublicService.Search(model4);
